Blueprint Reading for the Machine Trades, 8th edition
- Russ R. Schultz
- , Larry Lorenzo Smith
Learn more, spend less
- Find it fast
Quickly navigate your eTextbook with search
- Stay organized
Access all your eTextbooks in one place
- Easily continue access
Keep learning with auto-renew
Blueprint Reading for the Machine Trades systematically teaches you the skills needed to read and interpret blueprints. You'll master each new concept through immediate hands-on problem-solving. No prior blueprint reading knowledge or specialized materials are required.
The content follows a logical progression. It begins with basic print reading, then moves to visualization and finally, to multiview drawings. New material is followed by assignments so you can immediately apply concepts. Questions pertaining to previously introduced material appear throughout the text.
The 8th Edition reflects the latest industry standards, including ASME Y14.5-2009 and CAN3-B78.1-M83. The text has proven itself useful both in classroom and industrial settings, and has also been widely used in self-teaching.
Published by Pearson (July 15th 2022) - Copyright © 2023
ISBN-13: 9780137840298
Subject: Welding
Category:
UNIT 1
- 1.1 Dictionary of Terms
- 1.2 Standard Abbreviations
- 1.3 Alphabet of Lines
UNIT 2
- 2.1 Dimensioning Systems
- 2.2 Blueprints
- 2.3 Engineering Drawings
- 2.4 Title Blocks
- 2.5 Drawing Notes
- 2.6 Single-View Drawings
- 2.7 Detail Drawings
- 2.8 Center Lines
- 2.9 Diameters and Radii
- 2.10 Break Lines
- 2.11 Typical Dimensions
- 2.12 Tolerances
- 2.13 Bolt Circles
- 2.14 Maximum Material Condition and Least Material Condition
- 2.15 Allowance
- 2.16 Arcs and Circles
UNIT 3
- 3.1 Orthographic Projection
- 3.2 Third-Angle Projection
- 3.3 First-Angle Projection
- 3.4 Isometric Sketching
UNIT 4
- 4.1 Reading Multiview Drawings
- 4.2 Precedence of Lines
- 4.3 Accumulated Tolerances
- 4.4 Dimensioning Methods
UNIT 5
- 5.1 Orthographic Projection of Inclined Planes
- 5.2 Foreshortened Views
- 5.3 Angular Dimensions
- 5.4 Included Angle
- 5.5 Slots and Grooves
UNIT 6
- 6.1 Reference Dimensions
- 6.2 Blind Holes
- 6.3 Chamfers
- 6.4 Keyseats and Keyways
- 6.5 Counterbores and Countersinks
- 6.6 Angular Hole Locations
- 6.7 Castings
- 6.8 Finish Symbols
- 6.9 Finish Allowance
- 6.10 Fillets and Rounds
- 6.11 Clearance Holes
- 6.12 Half-Views
- 6.13 Starting Dimensions
- 6.14 Surface Roughness
- 6.15 Roughness Average (Ra)
- 6.16 Surface Roughness Chart
- 6.17 Surface Texture Symbol
UNIT 7
- 7.1 Bosses and Pads
- 7.2 Slotted Holes
- 7.3 Casting Dimensions
- 7.4 Tapers
- 7.5 Standard Tapers
- 7.6 Necks
- 7.7 Limits
- 7.8 Single Limits
- 7.9 Steel Processing
- 7.10 Steel Specifications
- 7.11 General Properties of Alloy Steels
- 7.12 Steel Carbon Content
- 7.13 Partial Enlarged Views
- 7.14 Stock Sizes
- 7.15 Knurling
- 7.16 Heat-Treat Notes
UNIT 8
- 8.1 Sectional Views
- 8.2 Full Sections and Half-Sections
- 8.3 Wall Thickness
- 8.4 Symbology
- 8.5 Annular Grooves
- 8.6 Cast Iron
- 8.7 Spotfacing
- 8.8 Revolved Sections
- 8.9 Broken-Out Sections
- 8.10 Ribs in Section
- 8.11 Rotated Features
- 8.12 Removed Sections
- 8.13 Offset Sections
UNIT 9
- 9.1 Threaded Hole Specifications
- 9.2 Unified Thread Form
- 9.3 Thread Series
- 9.4 Classes of Fit
- 9.5 Threaded Hole Illustrations
- 9.6 Thread Calculations
- 9.7 Constant Pitch Series
- 9.8 Line Omission
- 9.9 Arrowless Dimensioning
- 9.10 External Threads
- 9.11 Thread Forms
- 9.12 Tabulated Dimensions
- 9.13 Multiple Threads
- 9.14 Pipe Threads
- 9.15 Dryseal Pipe Threads
- 9.16 Hex Bar Stock
UNIT 10
- 10.1 Typical Dimensions
- 10.2 Right Triangles
- 10.3 Repetitive Features
- 10.4 Detail Drawings
- 10.5 Drawing Revisions
- 10.6 Conical Tapers
- 10.7 Rockwell Hardness Test
- 10.8 Thread Specification Placement
- 10.9 Patent Drawings
UNIT 11
- 11.1 Metric Drawings
- 11.2 Dimensioning Symbols
- 11.3 Metric Threads
- 11.4 Dimension Conversion: Metric to Inch and Inch to Metric
- 11.5 Coordinate Dimensioning
- 11.6 Dual Dimensioning
- 11.7 Dimension Origin
UNIT 12
- 12.1 Auxiliary Views
- 12.2 Inclined Planes
- 12.3 Oblique Planes
- 12.4 Bend Allowance
UNIT 13
- 13.1 Geometric Tolerancing
- 13.2 Feature Control Frame
- 13.3 Material Condition Symbols
- 13.4 Projected Tolerance Zone
- 13.5 Basic Dimension Symbol
- 13.6 Between Symbol
- 13.7 Datum Feature Symbol
- 13.8 Combined Symbols
- 13.9 Composite Frames
- 13.10 Datum Target Symbol
- 13.11 Form Tolerances
- 13.12 Datums and the Datum Reference System
- 13.13 Orientation Tolerances
UNIT 14
- 14.1 Location Tolerances
- 14.2 Runout Tolerances
- 14.3 Projected Tolerance Zone
- 14.4 Profile Tolerances
- 14.5 All Over and All Around Symbols
- 14.6 Unilateral and Unequally Disposed Profile Tolerance
- 14.7 Geometric Characteristic Symbols
- 14.8 Former Practices
- 14.9 Comparison of Symbols
UNIT 15
- 15.1 Spur Gear Terminology
- 15.2 Spur Gear Formulas
- 15.3 Spur Gears
- 15.4 Splines
UNIT 16
- 16.1 Weldments
- 16.2 Welding Symbols
- 16.3 Resistance Welds
Math Appendix
